BIOS boot:

The computer motherboard is the main backbone of the computer. It has physical circuits and uses circuits to connect various components. The users, software programs and input devices can control the operation of the logic circuits on the motherboard. However, to boot from the shutdown state, the initialization software instructions must be executed.

Most motherboards' BIOS are stored in Flash ROM chips, which are used to initialize the motherboard. During the boot process, memory and peripheral devices will be tested and initialized. This process is called power-on self-test (POST). If an error occurs during the POST process, the host will emit a "beep" sound or an error message will appear on the screen.

Since 2011, most retail motherboards have adopted UEFI BIOS, and some manufacturers (especially MSI Technology and ASUS) have also taken the lead in introducing technologies such as graphical interface UEFI BIOS.

Since Pentium III, motherboard manufacturers have gradually added overclocking functions to BIOS. However, since the Intel Sandy Bridge microarchitecture, Intel has greatly restricted overclocking. Intel processors that do not support overclocking (such as most desktop Intel Core processors that do not end with K) are difficult to overclock. AMD has an open attitude and does not prohibit players from overclocking. This situation did not stop until the AMD Ryzen series, when AMD locked the A320 motherboard. OEM motherboard BIOS usually does not support overclocking. For stability reasons, server overclocking is not allowed.

Today, we show you a hot selling style Angxun H81 Chipset Series Motherboard, which is Angthumb X58-V310-S3,the following parameters are supported：

▲Support Intel Core i7/i5/i3/Pentium/Celeron LGA1150 Series Processor

▲Support 4 SATA interface,10* USB ports

▲Support high speed DDR3 dual channel memory slot

▲Support 1066/1333/1600MHz, maximum capacity 16GB

▲Support 5.1 Audio channel ALC897 chip

▲Support increasing transmission speed of USB3.0

▲Support for PCIE expansion 2 slots

▲ Support RJ45 Gigabit LAN interface

▲Support WIN7,WIN10 32/64 bit operating system

Angxun has been in the motherboard industry for more than 20 years. Registered the brand Angthumb in many countries,we have focused on the production and research and development of intel motherboard,all in one motherboard,and Industrial motherboard,server motherboard ，RAM,SSD,CPU,GPU etc.The website is : www.angthumb.com to know more!
